Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 4.5 - 5.0 mm |
Screw length | — |
Min. drill hole depth | — |
Min. screw length ( ls ) | tfix + 55 mm |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | ls - 55 mm |
Contents | — |
Packaging | Folding box |
Amount | 50 pcs. |
GTIN (EAN-Code) | 4048962254075 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 4.5 - 5.0 mm |
Screw length | — |
Min. drill hole depth | — |
Min. screw length ( ls ) | tfix + 60 mm |
Anchor length ( l ) | 50 mm |
Max. fixture thickness | — |
Contents | 20 x DuoTec 10 |
Packaging | Folding box |
Amount | 20 pcs. |
GTIN (EAN-Code) | 4048962254099 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 4.5 - 5.0 mm |
Screw length | — |
Min. drill hole depth | — |
Min. screw length ( ls ) | tfix + 60 mm |
Anchor length ( l ) | 50 mm |
Max. fixture thickness | — |
Contents | 2 x DuoTec 10 |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962254112 |
Drill diameter ( d0 ) | 12 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 50 mm |
Screw diameter ( ds ) | 5.0 - 6.0 mm |
Screw length | — |
Min. drill hole depth | — |
Min. screw length ( ls ) | tfix + 65 mm |
Anchor length ( l ) | 60 mm |
Max. fixture thickness ( t fix ) | ls - 65 mm |
Contents | — |
Packaging | Folding box |
Amount | 10 pcs. |
GTIN (EAN-Code) | 4048962299830 |
Drill diameter ( d0 ) | 12 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 50 mm |
Screw diameter ( ds ) | 5.0 - 6.0 mm |
Screw length | — |
Min. drill hole depth | — |
Min. screw length | — |
Anchor length ( l ) | 60 mm |
Max. fixture thickness | — |
Contents | — |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962299885 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 60 mm |
Min. drill hole depth ( h1 ) | 65 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | 27 mm |
Contents | — |
Packaging | Folding box |
Amount | 25 pcs. |
GTIN (EAN-Code) | 4048962254082 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 60 mm |
Min. drill hole depth ( h1 ) | 65 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | 27 mm |
Contents | 10 x DuoTec 10 10 x Screw 5.0 x 60 |
Packaging | Folding box |
Amount | 10 pcs. |
GTIN (EAN-Code) | 4048962254105 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 60 mm |
Min. drill hole depth ( h1 ) | 65 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | 27 mm |
Contents | 2 x DuoTec 2 x Screw 5.0 x 60 |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962254129 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 60 mm |
Min. drill hole depth ( h1 ) | 65 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | 27 mm |
Contents | — |
Packaging | Folding box |
Amount | 25 pcs. |
GTIN (EAN-Code) | 4048962267426 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 60 mm |
Min. drill hole depth ( h1 ) | 65 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | 27 mm |
Contents | 10 x DuoTec 10 10 x Panhead screw 5.0 x 60 |
Packaging | Folding box |
Amount | 10 pcs. |
GTIN (EAN-Code) | 4048962267433 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 60 mm |
Min. drill hole depth ( h1 ) | 65 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness ( t fix ) | 27 mm |
Contents | 2 x DuoTec 10 2 x Panhead screw 5.0 x 60 |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962267440 |
Drill diameter ( d0 ) | 12 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 50 mm |
Screw diameter ( ds ) | M6 mm |
Screw length ( ls ) | 70 mm |
Min. drill hole depth | — |
Min. screw length | — |
Anchor length ( l ) | 60 mm |
Max. fixture thickness | — |
Contents | 10 x DuoTec 12 10 x Panhead screw M6 x 70 |
Packaging | Folding box |
Amount | 10 pcs. |
GTIN (EAN-Code) | 4048962299847 |
Drill diameter ( d0 ) | 12 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 50 mm |
Screw diameter | — |
Screw length | — |
Min. drill hole depth | — |
Min. screw length | — |
Anchor length ( l ) | 60 mm |
Max. fixture thickness | — |
Contents | — |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962299892 |
Drill diameter ( d0 ) | 10 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 40 mm |
Screw diameter ( ds ) | 5.0 mm |
Screw length ( ls ) | 84 mm |
Min. drill hole depth ( h1 ) | 66 mm |
Min. screw length | — |
Anchor length ( l ) | 50 mm |
Max. fixture thickness | — |
Contents | 2 x DuoTec 10 2 x Round hook 5.0 x 84 |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962254136 |
Drill diameter ( d0 ) | 12 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness ( dp ) | 55 mm |
Min. cavity depth ( a ) | 50 mm |
Screw diameter ( ds ) | 5.5 mm |
Screw length ( ls ) | 70 mm |
Min. drill hole depth ( h1 ) | 75 mm |
Min. screw length | — |
Anchor length ( l ) | 60 mm |
Max. fixture thickness | — |
Contents | — |
Packaging | — |
Amount | 10 pcs. |
GTIN (EAN-Code) | 4048962299854 |
Drill diameter ( d0 ) | 12 mm |
Min. panel thickness ( dp ) | 9,5 mm |
Max. panel thickness | — |
Min. cavity depth | — |
Screw diameter ( ds ) | 5.5 mm |
Screw length | — |
Min. drill hole depth | — |
Min. screw length | — |
Anchor length ( l ) | 60 mm |
Max. fixture thickness | — |
Contents | — |
Packaging | Blister card |
Amount | 2 pcs. |
GTIN (EAN-Code) | 4048962299908 |
