FireBarrier ElastoSeal Plus FFB-ES Plus
  • Product Picture: "fischer FireBarrier ElastoSeal Plus FFB-ES Plus RED"
  • Application Picture
  • Application Picture
  • Application Picture
  • Youtube VideoYoutube VideoYoutube Video
    • Youtube VideoYoutube VideoYoutube Video
    • Product Picture
    • Application Picture
    • Application Picture
    • Application Picture
      Objednávacie číslo 569304

      fischer FireBarrier ElastoSeal Plus FFB-ES Plus RED

      Varianty produktov
      Download of image data
      Top Features
      • Movement capability ± 25 % according to EN 1366-4.
      • Cycling up to 500 times, 15 % movement as of ASTM E1399 (Class II and III).
      • 1.6 mm WFT required.
      • Designed for use with 60 kg/m3 stonewool base.
      • Low VOC, halogen and solvent free.

      Výhody / popis produktu

      Flexible fire resistant acrylic spray
      Advantages
      • 1.6 mm WFT required
      • Spray or brush applied
      • Acoustic properties (EN ISO 10140-2 and ASTM E90)
      • Air permability (EN 1026)
      • Water permability (EN 1027)
      • Paintable
      • Low VOC, halogen and solvent free.
      • The shelf life is 24 months.
      fischer FFB-ES Plus is a one part water-based acrylic spray which has been designed to provide smoke and fire protection on horizontal construction joints, vertical penetrations and perimeter joints. Tested in accordance with EN 1366-3, EN 1366-4, EN 1364-4, ASTM E1966 (UL 2079) the FFB-ES Plus is certified by ETA, UL-EU and UL-US. It has excellent movement capabilities and applied together with stone wool backing it provides up to 4 hours fire rating.
      Youtube VideoYoutube VideoYoutube Video

      Žiadosť a schválenie

      Applications
      • Horizontal linear joints (EN 1366-4)
      • Perimeter joints (EN 1364-4)
      • Horizontal linear joints (ASTM E1966/UL 2079)
      • Internal application
      Building materials
      • Rigid floor and wall constructions
      • Masonry
      • Concrete
      • Aerated Concrete
      Podrobné informácie o stavebných materiáloch nájdete v schválení. Ďalšie dokumenty nájdete v časti https://www.fischer.de/sdb.
      Schválenia
      • ETA-23/0164
      • ETA-23/0166
      • DoP No. FS-1018
      • DoP No. FS-1019
      • UL-EU-01276-EN
      • EPD-DBC-FIW-20230413-IBF1-EN

      Montážny návod

      Functionality
      • FFB-ES Plus is a one part water-based fire resistant spray, which prevents the passage of smoke and fire between fire rated compartments.
      • Can be used for internal application and for conditions where dynamic movement may occur.
      • Acoustic properties (EN ISO 10140-2 and ASTM E90)
      • Air permability properties (EN 1026)
      • Water permability properties (EN 1027)
      Installation FFB-ES Plus perimeter joint
      1 / 6
      • 1
        Installation FFB-ES Plus perimeter joint
      • 2
      • 3
      • 4
      • 5
      • 6
      Installation FFB ES Plus penetration
      1 / 4
      • 1
        Installation FFB ES Plus penetration
      • 2
      • 3
      • 4
      Installation FFB-ES Plus joint
      1 / 5
      • 1
        Installation FFB-ES Plus joint
      • 2
      • 3
      • 4
      • 5

      Špecifikácie

      ETA-approval
      Contents 19 l
      Colour red
      Airborne sound insulation (ISO 10140-2) Rw (C, Ctr) = 44 (-4, 9) dB
      Sound Transmission Class STC (ASTM E90) STC 62
      Shelf life 24 months
      Packaging Bucket
      Amount 1 pcs.
      GTIN (EAN-Code) 4048962494884

      Dokumenty na stiahnutie

      • ETAs and DoPs
      • Approvals and Certificates
      • Sustainability
      • Safety data sheets
      • Technical documents
      ETA Certification Document
      pdf, ETA-23/0164
      European Technical Assessment for fischer FFB-ES Plus - Fire Stopping, Fire Sealing & Fire Protective Products, Fire Retardant Products, Penetration Seals.
      Vytvorené dňa 11/28/2023
      DOP - Declaration of Performance
      pdf, DoP No. FS-1018
      Declaration of Performance for fischer FFB-ES Plus ElastoSeal (Fire stopping and fire sealing products: Penetration Seals)
      Vytvorené dňa 12/05/2023
      ETA Certification Document
      pdf, ETA-23/0166
      European Technical Assessment for fischer FFB-ES Plus - Fire Stopping, Fire Sealing & Fire Protective Products, Fire Retardant Products, Linear Joint and Gap Seals.
      Vytvorené dňa 11/28/2023
      DOP - Declaration of Performance
      pdf, DoP No. FS-1019
      Declaration of Performance for fischer FFB-ES Plus ElastoSeal (Fire stopping and fire sealing products: Linear Joint and Gap Seals)
      Vytvorené dňa 12/05/2023
